• Headlamps, halogen projector-beam
• Bumper, front, Black
• Grille, base, molded in color, Black
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Lamps, cargo area, cab mounted with switch on center switch bank
• Front fender extension, painted body color
• Assist steps
• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Spare tire delete (STD)
• Wheel, spare delete
• Door handles, Black
• Lamps, Smoked Amber roof marker
• Auxiliary harness, 3' for headlamps and turn signals
• Mirrors, outside heated power-adjustable vertical trailering, upper glass, manual-folding and extending, black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
• Glass, deep-tinted
• Grille guard screen, stone protection (mounted to bumper)
• Summit White
• Tires, rear 225/70R19.5H Traction blackwall Continental Max Axle Load: 15,500 lb.
• Oil seal for front hub, Chicago Rawhide Nitrile for oil lubricated wheel bearings
• License plate kit, front
• Electrical Provisions, rear of frame, upfitter, body builder wiring includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
• Paint Scheme, Style 1
• Tires, front 225/70R19.5H BW HWY Continental Max Axle Load: 8,000 lb.
• Tire valve cap, Haltec flow-thru
• Fog lamps, front, halogen
• Paint, solid
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Spare tire delete (STD)
• Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp

• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Steering column, manual Tilt-Wheel
• Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Mirror, inside rearview manual day/night
• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Defogger, rear-window electric
• Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
• Windows, power with driver express up and down and express down on all other windows
• Seat Belt, Orange (center seat belt will ship loose)
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Chevrolet Connected Access capable
• Power outlet, 110-volt AC
• Label, fasten seat belts "Fasten Seat Belts" reminder label on right hand and left hand front side door glass
• Remote Keyless Entry

• Steering, power (Bosch S2 8014 Plus)
• Emissions, USA 50 State certified
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Trailer brake controller, integrated
• Rear axle, 4.30 ratio Max road speed: 75 MPH
• Front axle, 7,500 lb., Dana Spicer 60-256, single-reduction, front driving
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Axle lubricant, front, synthetic oil EmGard FE-75W-90
• Exhaust brake
• Four wheel drive
• Front suspension, 7,500 lb. (3,402 kg) multi-leaf, includes shock absorbers
• Emissions, 50 state certification
• Exhaust system, rear exit
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Axle to End of Frame, 91"
• Rear suspension, 15,500 lb. (7,031 kg) multi-leaf, vari-rate
• Rear axle, 4.30 ratio Max road speed: 75 MPH
• Wheelbase, 231" (586.7 cm), 150" CA
• Skid Plate, steel, frame-mounted, protects the transfer case from the ground
• 6500 HD Series
• Rear axle, 15,500 lb. (7,031 kg), Dana Spicer S16-130, single reduction
• Alternator, 220 amps
• Recovery hooks, front, frame-mounted, black
• 34,000 lb. GCWR (15,422 kg)
• GVWR, 22,500 lb. (10,206 kg)
• Batteries, heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
• DPF, diesel particulate filter, manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
• Battery, top post threaded, battery jump start stud (located on battery box)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Fuel tank, front and rear, 65 gallon total

• Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
• Work Truck Preferred Equipment Group includes standard equipment

• Fleet Processing Option

• Daytime Running Lamps, with automatic exterior lamp control

• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• OnStar and Chevrolet connected services capable Includes compass in instrument cluster.
• Horn, dual-note

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• DriveType
• DriveType: Four Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 65 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
